Low Temperature Viton™ (FKM GLT, GFLT, XLT) Selection Guide
Low temperature Viton™, a type of fluoropolymer elastomer, is renowned for its excellent resistance to chemicals and ability to perform in extreme environmental conditions, including low temperatures. This webpage provides an overview of the different types of low temperature Viton™, highlights its advantages and disadvantages, and examines its use in various industrial applications, especially focusing on O-rings, gaskets, and custom parts.
The engineers and consultants here at Canyon Components take pride in finding the perfect seal to suit our customer’s needs. Contact our expert staff for assistance with any seal or application questions!
Common names include: FKM (Fluorocarbon), Fluoropolymer. Trade Names: Viton™, Fluorel®, Technoflon®, Dai-El®, FEPM.
![Low temperature viton, glt, gflt, xlt O-ring](https://cancomp.nyc3.cdn.digitaloceanspaces.com/Pub/img/prts/Elst/O-ring-Low%20Temp2.png)
![Viton Low Temperature O-rings](https://cancomp.nyc3.cdn.digitaloceanspaces.com/Pub/img/prts/Elst/O-ring-Low%20Temp.png)
Request a Quote for Low Temperature Viton™
Features of Low Temperature Viton™
- Chemical Resistance: Exceptional resistance to oils, fuels, lubricants, and most mineral acids, making it ideal for harsh chemical environments.
- Thermal Range: Although primarily known for high temperature resistance, low temperature Viton™ maintains good mechanical properties at significantly lower temperatures than standard FKM materials.
- Durability: Known for its durability and longevity, reducing the need for frequent replacements of O-rings, gaskets, and custom parts.
- Versatility: Suitable for a wide range of applications due to its strength and chemical compatibility.
Limitations of Low Temperature Viton™
- Cost: More expensive than many other elastomers, due to its specialized properties and performance advantages.
- Limited Flexibility: While improved, low temperature Viton™ is still less flexible than some other low temperature elastomers like silicone or PVMQ.
- Color and Appearance: Typically available in fewer colors and finishes, which may be a consideration in applications where aesthetics are important.
Please consult a Canyon Components Engineer about your specific application and we will use our decades of experience to formulate a solution that fits your need.
FKM & Viton™ High Performance Polymer Types
There are many types of FKM Polymer Types that Canyon Components offers.
This includes FKM Types A, B, F, GLT, GFLT, XLT, ULT, ETP, & TBR.
The table below is a Viton™ selection guide that lays out the pluses and minuses of each variation.
Key: 1 = Excellent 2 = Good 3 = Poor 4 = Not Recommended
Types of FKM | A | GF | GLT | GLT ED | GFLT | XLT | ETP | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Canyon Compound Number | VT75BK00 | VT75BK20 | VT75BK30 | VT90BK31 | VT75BK40 | VT75BK50 | VT75BK60 | |||||||
Description | General Purpose | General Purpose High Fluorine |
Low Temp | Low Temp Resistant to Explosive Decompression |
Low Temp High Fluorine |
Extreme Low Temp High Fluorine |
Viton® Extreme High Fluorine FEPM |
|||||||
Cure Type | Bisphenol | Peroxide | Peroxide | Peroxide | Peroxide | Peroxide | Peroxide | |||||||
Typical Fluorine Content | 66 | 69.5 | 64 | 64 | 66.5 | 66.5 | 67 | |||||||
Typical High Temp Range °F (°C) | 437 (225) | 437 (225) | 437 (225) | 437 (225) | 437 (225) | 437 (225) | 437 (225) | |||||||
Typical Low Temp Range °F (°C) | -15 (-26) | -15 (-26) | -40 (-40) | -40 (-40) | -35 (-37) | -54 (-48) | -6 (-21) | |||||||
TR-10 °F (°C) | 1 (-17) | -6 (-21) | -22 (-30) | -22 (-30) | -11 (-24) | -40 (-40) | 12 (-11) | |||||||
Oxygenated Automotive Fuels (containing MeOH, EtOH, MTBE, etc.) | 4 | 1 | 4 | 4 | 1 | 1 | 1 | |||||||
Reciprocating Engine Lubricating Oils (SE-SF Grades) | 2 | 1 | 1 | 1 | 1 | 1 | 1 | |||||||
Aliphatic Hydrocarbon Process Fluids,Chemicals | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |||||||
Aromatic Hydrocarbon Process Fluids, | 1 | 1 | 2 | 2 | 1 | 1 | 1 | |||||||
Aqueous Fluids: Water, Steam, Mineral Acids (H2SO4, HNO3, HCl, etc.) | 3 | 1 | 1 | 1 | 1 | 1 | 1 | |||||||
Amines, High pH Caustics | 4 | 4 | 4 | 4 | 4 | 4 | 1 |
Industrial Usage of Low Temperature Viton™
Low temperature Viton™ is a versatile, durable material essential for creating O-rings, gaskets, and custom parts that need to withstand harsh conditions without compromising performance. Its ability to operate under extreme cold and resist aggressive chemicals makes it an invaluable material in critical applications across various industries. Despite its higher cost and somewhat stiffer composition, the benefits of low temperature Viton™ often outweigh these challenges, making it a preferred choice for many high-stakes environments.
Canyon Components strives to meet all customer service requests. Feel free to contact Canyon Components engineering and let our knowledgeable staff help you design the perfect part for your needs.
Oil and Gas Industry
Crucial for O-rings, gaskets, and custom parts in systems exposed to extreme cold and harsh chemicals, including offshore rigs and refineries.
Chemical Processing
Employed in the production of seals and valves that must operate reliably in the presence of aggressive chemicals at variable temperatures.
Automotive
Utilized in fuel system seals, O-rings, and gaskets where resistance to biodiesel, fuels, and lubricants is critical, even in cold climates.
Aerospace
Provides essential components such as O-rings and seals that can withstand both the chemical exposure and temperature extremes encountered in aerospace applications.
Energy Sector
Used in equipment in renewable energy installations, particularly in cold environments where chemical stability and material integrity are paramount.
Please consult a Canyon Components Engineer about your specific application and we will use our decades of experience to formulate a solution that fits your need.
